I-10l iqokelele yomatshini wokubetha

Model:KGB70A

I-KGB70A yinkqubo yokuqulunqa i-10L ye-10L ye-Floung ye-Folds eyenzelwe ukuba i-max yebhotile yebhotile eyi-15 yebhotile yebhotile. Njengomenzi webhotile ekhokelayo yebhotile, sinikezela ngezisombululo ezihleliweyo zokufikelela kwiimfuno zomthengi. Umatshini ayisiyiyo kuphela iibhotile zamanzi, izikhongozeli zokubulala izitshabalalisi, kunye nemveliso yokupakisha yemidlalo yemihla ngemihla, kodwa nakwimveliso encinci kodwa ekhethekileyo. Lo matshini udibana neemfuno ezahlukeneyo.

Umthamo: 20lUbunzima: 7.8T

Thumela uMbuzo

Ingcaciso yeMveliso Specification Application

I-KGB70A I-10T ye-10l iqokelelwa ngumatshini wokuvuthuza kukuvula nokuvalwa Imodeli, eyamkela i-respt pall rod rod i-rod synchronous yenqwaba, ioyile I-Cylinder uxinzelelo ngqo lokutshixa i-Poight, i-cylinder diefir fi I-Holdralic servo System yolawulo, isantya sokuphendula ngokukhawuleza kunye nokugcinwa kwamandla.
I-Suite engakumbi kwimveliso ekhethekileyo yoyilo lwemveliso, inokwenzeka Lawula ubume kunye nobungqingqwa ngokuchanekileyo.

Iimpawu kunye nezibonelelo

Le modeli yindawo yokuvula evulekileyo kunye nokuvala i-pie rand ranchronous yefilimu, kunye ne-oyile cylind yoxinzelelo
● Ukugcina i-cylinder fele the the craction
● Elona nani liphezulu i-20l
● Ilungele iibhotile zamanzi, izikhongozeli zokubulala izitshabalalisi, kunye nokupakishwa kwemichiza yemihla ngemihla, njl.
● Inqaku elahlukileyo kukuba lilawulwa yinkqubo ye-hydraulic senso yokufezekisa impendulo yendlela yokukhawuleza kunye nokuphumelela kwamandla aphezulu.

Specifications

serial number	Material PE、PP、ABS ...	Mold closing oil cylinder(single cylinder)
serial number	Material PE、PP、ABS ...	Machine model:KGB70A
Specifications
1	Max container capacity	20L
2	Output(dry Cycle)	700 PC/HR
3	Machine Dimension(L×W×H)	4.3 M x1.7 M x3.9 M
4	Machine weight	7.8 T
Clamping Unit
1	Clamping force	130 KN
2	Mold platen size(W×H)	680 MM x 600 MM
3	Platen openingstroke	300 MM - 850 MM
4	Platen moving stroke	370 MM
5	Max mold size(W×H)	460 MM×600 MM
6	Mold thickness	310 MM - 380 MM
Power
1	Servooil pump motor power	11KW
2	Servo pump displacement	80 L/MIN
3	Blowpressure	0.8 Mpa
4	Air consumption	0.7 M²/MIN
5	Cooling water pressure	0.3 Mpa
6	Water consumption	60 L/min
7	Average energy consumption	18 KW-22 KW
Extruder unit
1	Screw diameter	70 MM
2	Screw L/D ratio	24 L/D
3	Melting capacit for HDPE	80 Kg/hr
4	Number of heating zone	3 ZONE
5	Screw heating power	12.6 KW
6	Screw fanpower	0.5 KW
7	Extruder motor power	22 KW
Die head
1	Number of heating sections	5 ZONE
2	Heating power	20 KW
3	Maxdie-pin diameter	180 MM
4	Accumulator capacity	3 L
5	(PE)Accumulator weight	2.25 KG
