I-5l isitishi esiphindwe kabini kuvuthuza umatshini wokubumba

Model:KGB5D

Yandisa imveliso yakho kunye ne- Lo matshini wokusebenza ophezulu ubonelela ngokucwangciswa okuguqukayo, kubandakanya i-2, 3, okanye i-4 yeentloko zeNtloko yeNtloko, ukulungiselela uluhlu olubanzi lweesayizi.

Umthamo: 5LUbunzima: 5.2T

Thumela uMbuzo

Ingcaciso yeMveliso Specification Application

Ukusuka kwiibhotile zevolumu ezincinci ukuya kwizikhongozeli ze-5l ezinkulu, esi sitishi sesibini esiphindwe kabini kuvuthuza umatshini uqinisekisa imveliso efanelekileyo kunye nomgangatho oqinisekileyo. Ilungele izicelo ezahlukeneyo, Kubandakanya i-Laundry Computer Computer Plates Scovals Scolutions, yona Ihambisa iziphumo ezizodwa kwaye yandise imbuyekezo yakho kutyalo-mali.

Iimpawu kunye nezibonelelo

● Isikhululo sesikhululo sokuguqula kabini esiguqukayo, sisebenzisa i-buffer ye-buffer ivalve yokutshintsha, efanelekileyo kwaye izinzile
● Intloko yokufa yanceda ifom yokondla iziko
● Inkqubo yokulawulwa kwe-elektroniki yamkela i-MUTSGISI ye-MUTSCIIP ye-PATS, kunye namaqhosha ozimeleyo ethunzini aququzelela ukulungiswa komsebenzisi kunye nohlengahlengiso.
● Ivolumu yemveliso ephezulu yi-5L, esona sixhobo sokutsalwa kwezinto esithandwayo semveliso yobunzima engaphantsi kwe-2-5l.
● Ngokutsho kweempawu, inokwahlulwa ibe yingoma eyodwa, umaleko ophindwe kabini, umaleko amathathu, umgca obonakalayo, njl.
● Inkqubo ye-hydraulic yamkela uyilo lodwa, ukusebenza okuphezulu kunye nesantya esikhawulezayo

Specifications

Serial number	Material PE、PP、PVC、PA...	Mold-moving series
Serial number	Material PE、PP、PVC、PA...	Machine model:KGB5D
Specifications
1	Max container capacity	5L
2	Output(dry Cycle)	500 PC/HR x2 PC/HR
3	Machine Dimension(L×W×H)	3.2 M×2.2 M×2.5 M
4	Machine weight	5.2 T
Clamping Unit
1	Clamping force	65 KN
2	Mold platen size(W×H)	368 MMx450 MM
3	Platen openingstroke	188 MM-538 MM
4	Platen moving stroke	420 MM
5	Max mold size(W×H)	410 MM×450 MM
6	Mold thickness	200 MM-310 MM
Power
1	Servooil pump motor power	15 KW
2	Servo pump displacement	100 L/MIN
3	Blowpressure	0.6 Mpa
4	Air consumption	0.7 M³/MIN
5	Cooling water pressure	0.2 Mpa-0.3 Mpa
6	Water consumption	80 L/min
7	Average energy consumption	16 KW-25 KW
Extruder unit
1	Screw diameter	70 MM
2	Screw L/D ratio	25 L/D
3	HDPEMelting capacit for HDPE	80 Kg/hr
4	Number of heating zone	3 ZONE
5	Screw heating power	12.6 KW
6	Screw fanpower	0.25 KW
7	Extruder motor power	22 KW
Die head
1	Number of heating sections	3*8 ZONE
2	Heating power	3.7 KW
3	1MT Max die-pin diameter	150 MM
4	2 Center distance of double die head	150 MM-180 MM
5	2MT Max die-pindiameter	80 MM
