Isantya esiphezulu se-15L STATES SEBENZISIWEYO

Model:KGH15L

Dlulisa amandla akho emveliso nge-KGh15l Speef Isantya se-15L Sheet Sheat Plassing, unokukhetha intloko ye-5l ye-5l ye-5l ye-5l yomatshini we-5l Isitayile sengalo esijikelezayo sokuhambisa isixhobo sokubonelela ngamandla amakhulu e-clmping, yenza ubume obugqibeleleyo / ubume be-barrel.

Umthamo: 15lUbunzima: 7.5T

Thumela uMbuzo

Ingcaciso yeMveliso Specification Application

I-KGH15L isikhawulezisi esiphezulu se-15L isikhululo sayohlwaya umatshini wokubetha ayisiyogama nje, kodwa liqabane lobuchule kumashishini ujonge ukuphucula ukuveliswa kwengqondo. Inkxaso yayo yoyilo Ukwandiswa kwexesha elizayo kunye nophuculo, ukuyenza ihambelane neemodyuli ezenzekelayo ezinje ngeCandelo lokuShushu ngokuzenzekelayo kunye nokuhlolwa kwe-Intanethi, ukunceda iifektri ziyahamba kwishishini 4.0.

Iimpawu kunye nezibonelelo

I-sloun yesikhululo esinye esiqhubekayo senziwe somatshini sokuvuthuza yenzelwe ukuveliswa komthamo omkhulu, ukubonelela ngokubhekiswa kunye nokusebenza kakuhle kwezikhongozeli ukuya kwi-15l. Uyilo lwayo lutsha luvumela ukutshintshelwa ngokulula phakathi kweentloko zentloko kunye ne-Multi-Dief, qinisekisa ukusebenza kakuhle kwimilinganiselo eyahlukeneyo yesayizi.
Lo matshini umele ukusebenzela okuphezulu, ukunika utshintsho olukhawulezileyo phakathi kolunye uhlengahlengiso lokwandisa iziphumo kunye nokunciphisa ixesha lokuphumla. Ikwahlobo, ekwaziyo ukuvelisa uluhlu olubanzi lwezikhongozeli ezivela kwiibhotile ze-shampoo ukuya kwii-jerrycans, zenza ukuba zilungele amashishini ahlukeneyo.
Ngomgangatho ophezulu, iqinisekisa ukuveliswa okungaguqukiyo ngokuchaneka, ukuhlangabezana nemigangatho ephezulu. Ukongeza, uyilo lwayo olusebenzayo lunciphisa iindleko zokusebenza ngelixa uphucula imveliso. Yakhelwe ukuthembeka, umatshini wenza ngokuqhubekayo ngeziphumo ezizinzileyo, naphantsi kweemeko ezinzima.
Phakamisa amandla akho evelisi kunye nolu matshini wokuzibhokoxa owaziwayo obonelela ngomgangatho ophakathi kunye nokusebenza kakuhle.

Specifications

Serial number	Material PE、PP、PVC、PA...	Mold-moving series
Serial number	Material PE、PP、PVC、PA...	Machine model:KGH15L
Specifications
1	Max container capacity	15 L
2	Output(dry Cycle)	450 PC/HR
3	Machine Dimension(L×W×H)	4.5 M x 2.2 M x 2.8 M
4	Machine weight	7.5 T
Clamping Unit
1	Clamping force	165 KN
2	Mold platen size(W×H)	500 MM x 550 MM
3	Platen openingstroke	280 MM -680 MM
4	Platen moving stroke	600 MM
5	Max mold size(W×H)	580 MM x 500 MM
6	Mold thickness	300 MM - 380 MM
Power
1	Servooil pump motor power	18.5 KW
2	Servo pump displacement	130 L/MIN
3	Blowpressure	0.6 Mpa
4	Air consumption	0.8 M³/MIN
5	Cooling water pressure	0.2 Mpa - 0.3 Mpa
6	Water consumption	70 L/min
7	Average energy consumption	25-34 KW
Extruder unit
1	Screw diameter	75 MM
2	Screw L/D ratio	25 L/D
3	Melting capacit for HDPE	100 Kg/hr
4	Number of heating zone	4 ZONE
5	Screw heating power	16 KW
6	Screw fanpower	0.6 KW
7	Extruder motor power	30 KW
Die head
1	Number of heating sections	3 * 8 ZONE
2	Heating power	6.5 KW
3	Maxdie-pin diameter	220 MM
4	Accumulator capacity	240 MM - 280 MM
5	(PE)Accumulator weight	150 MM
