I-183 yomatshini wetheyibhile yetafile

Model:KGS120Z

I-KGSEGY KGS120Z yitafile yetheyibhu yeplastiki ye-183 esenza ukuba isetyenziswe ngoomatshini betheyibhile ejikelezileyo yokuhambisa izicelo zeMuls. Itafile yeplastiki ngokupheleleyo okanye iplastiki yepakethi yepakethi yeplanga yokubetha yomatshini, inika uyilo olufihlakeleyo kunye nomgangatho ophezulu, ukunika umda okhuphiswano.

Umthamo: 1000lUbunzima: i-38t

Thumela uMbuzo

Ingcaciso yeMveliso

I-KGS120Z 183 Umatshini weTheyibhile yeTheyibhile yeTheyibhile yenziwa kwimveliso yeplastikhi yeplastikhi, enjalo Njengetafile / indlu yeWare njl. njl. dibana neemfuno zemveliso ekhethekileyo yemveliso, ngesantya esiphezulu imveliso ukugcina indleko zeyunithi.
Kubandakanya i-moog ye-Moog ye-100, ingalo yeRobot, kunye nezantsi Inkqubo yokuvwaza, ukuphucula imveliso kunye nomgangatho.

Inkcazo

Inombolo yesiriyeli	Izixhobo ze-HDPE ...	Isilinda esivale i-oyile (isilinda esinye)
Inombolo yesiriyeli	Izixhobo ze-HDPE ...	Imodeli yomatshini: KGS120Z
Inkcazo
1	Umthamo weShent yeAx	I-1000 l
2	Iziphumo (umjikelo owomileyo)	I-300 PC / hr
3	Ubungakanani boMatshini (l × × h)	8.3 m × 3.4 m × 6.8 m
4	Ubunzima boMatshini	38 t
Iyunithi yokutyhola
1	Ukunyanzelwa	I-1200n KN
2	Ubungakanani be-Worting Platen (× h)	I-1300 mm × 1900 mm
3	Iipleyiti zokuvula i-troke	I-600 mm-1600 mm
4	Ukubetha	I-700 mm
5	Ubungakanani bobumba (× h)	I-1000 mm × 2000 mm
6	Ubunzima bomnyama	I-630 mm - 830 mm
Amandla
1	I-serpooOl pump yeposti	I-25 kw
2	I-servo pump yokufuduka	I-200 l / min
3	Vutho	I-0.8 MPA
4	Ukusetyenziswa komoya	I-2 m² / mi
5	Uxinzelelo lwamanzi alupholayo	I-0.3 MPA
6	Ukusetyenziswa kwamanzi	I-120 l / min
7	I-avareji yokusetyenziswa kwamandla	I-110 kw -130 kw
Iyunithi ye-Experruder
1	Ububanzi be-screw	I-120 mm
2	Isikere l / d umlinganiselo	I-30 l / d
3	Ukunyibilika kwe-HDPE ye-HDPE	I-350 kg / hr
4	Inani lendawo yokufudumeza	I-6 yoMda
5	Isikhuseli sokufudumeza	32.5 Kh
6	I-screw fanpower	I-0.6 kw
7	Amandla emoto yangaphandle	I-90 kw
Intloko yokufa
1	Inani lamacandelo ashushu	I-5 yendawo
2	Ukufudumeza Amandla	38.8 Kh
3	Ububanzi be-maxdie	I-700 (800) mm
4	Umthamo oCwantiweyo	25 (30) l
5	(I-PE) Ubunzima be-accumulator	(22) kg

Iimpawu kunye nezibonelelo

Isetyenziselwa ukwenza iimveliso ezenziweyo kumashishini ahlukeneyo. Nokuba liyizikhongozelo ezinkulu zokungaziphathi kakuhle kwishishini lekhemikhali, iibhotile ezihamba ngendlela ecocekileyo kwishishini lokutya, okanye iibhokisi zokupakisha ngemveliso yekhemizi lemichiza, inokulawulwa ngokuchanekileyo ukuze ihambelane neemfuno ezahlukeneyo zentengiso.
Inkqubo yokondla yamkela itekhnoloji yokutshekisha kwaye ilungiselelwe ngokusekwe kwiimpawu zemveliso ephezulu ye-120z ye-120z ivuthuza umatshini wokubumba. Ukulawula ngokuchanekileyo ireyithi yokuhamba kunye nokusasazwa kwezinto ezingafunekiyo ukuqinisekisa ubuncwane obungudonga lwevolumu ngexesha lokubumba iimveliso zevolumu, kwaye zomeleze iziphene zemveliso, kunye nokuphelisa iziphene ezisemgangathweni ezibangelwa kukutya okungalinganiyo.
